Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
contacto

Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations

Quantidade de ordem mínima : 1 conjunto Preço : USD 1-10000/set
Detalhes da embalagem : Pollywood Tempo de entrega : 30-50 dias
Termos de pagamento : L/c, t/t, d/p Habilidade da fonte : 10 conjunto/mês
Lugar de origem: CHINA Marca: ZZ TOP OIL TOOLS
Certificação: ISO, API Número do modelo: Cabeça de controle de injeção de graxa

Informação detalhada
Produto: Cabeça de controle de injeção de graxa Material: Liga de aço
Pressão de trabalho: 10000psi Aplicativo: Operação do cabo
Uso: Equipamento de controle de pressão de cabo de aço Conexão: união de martelo
Wokring Temp.: -29～121℃
Destacar:

10000psi Grease Injection Control Head

,

Hammer Union Grease Injection Control Head

,

Alloy Steel Wireline Pressure Control Equipment

Descrição de produto

Grease Injection Control Head Assembly with Stuffing box and Wireline Wiper

The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.

Key Features
  • Positioned at the top of the pressure control equipment string
  • Combines Line Wiper Bell, Stuffing Box, Flow Tubes assembly, and ball check valve
  • Essential for maintaining well integrity during high-pressure operations
Technical Specifications
Wire Size Working Pressure Qty. Of Stuffing Box Qty. Of Flow Tubes Qty. Of Hydraulic Port Qty. Of Grease Injection Port Qty. Of Grease Return Port Service Working Temperature
7/32"
5/16"
15/32"		 5000Psi 1 4 2 1 1 STD or H2S P+U -20°F~+250°℉
Or As Required
10000Psi 1 6 2 1 1
15000Psi 2 9 3 2 1
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations 0
